Stage micrometers, SM-3

The SM-3 micrometre is useful in microscope calibration and many other optical magnification systems. The autolocation features can be used to evaluate an auto-location framework for image analysis.0.40 inch/10 mm X&Y Axis Linear Stage MicrometerTechnical DataSpecifications

The SM-3 micrometre is useful in microscope calibration and many other optical magnification systems. The autolocation features can be used to evaluate an auto-location framework for image analysis.

0.40 inch/10 mm X&Y Axis Linear Stage Micrometer

Technical Data

Specifications

Glass Size 25mm x 75mm ≥ 1.42mm thickness
Scale Length 0.04" (English) X & Y axis
10mm (Metric) X &Y axis
Divisions English = 0.0005"; Metric = 10µm (0.01mm)
With numerical labelling every 0.1mm and 0.05"
Image Forming Material Chrome
Image Contrast/Density Chrome transmission density is ≥ 2.0
Flatness ≤10µm/100mm
Feature Size Accuracy 2µm
Image Placement Accuracy 0.001 mm/100mm
Polarity Scales are opaque on a clear background
Reading Direction Right Read Chrome Up (RRCU)
Updated: 03-04-2025
Code Style Pack Size Availability Price Updated: 03-04-2025
EMS60210-3PG Chrome on glass Each 0 in stock (?) $691.00 AUD
EMS60210-3PGC With calibration Each 0 in stock (?) P.O.R. Quote
